Antec VP 600W Plus Non-Modular PSU
FEATURES
• Continuous Power - Guaranteed 600W Continuous Power from Antec
• 80 PLUS® 230V Standard Certified - Up to 85% efficient, to reduce your electricity bill
• AQ3 - Antec Quality 3 year warranty
• 120mm Silent Fan
• Thermal Manager - An advanced low voltage fan control for optimal heat & noise management
• CircuitShield™ - Full suite of industrial grade protections: UVP/OVP/SCP/OPP/NLO
• Multi PCI-E - 2 PCI-E connectors for multiple GPU support
The new generation of VP600P PLUS is crafted for quality, performance and incredible value.
This entry-level solution is rated from 500W to 700W, saving energy through its high efficiency of up to 85% efficient and is 80 PLUS® 230V Standard certified.
Delivering up to 85% efficiency, the VP P PLUS series utilizes active PFC, and provides efficiency during max and low loads—living up to the performance standards that we are known for.
3 Year Warranty
We stand by the quality and safety of the VP_P PLUS Power Supplies, offering a 3-year parts and labor warranty and unlimited access to our incomparable technical support and customer service.
120 mm Silent Fan
The 120 mm Silent Fan is ideal for quiet computing and is designed for longer life, guaranteeing hours of operation.
Features a Thermal Manager, an advanced low voltage fan control for optimal heat & noise management and will allow your PSU to stay at an optimal temperature.

Single 12V Rail Design


Cable Qty & length
TECHNICAL SPECS
Model VP600P PLUS
Modular Non-Modular
Dimension (W x L x H) 140(D)*150(W)*86(H)
Warranty 3 years
Input Voltage 200-240 VAC ±10%
Input Current 5A
Input Frequency Range 47Hz-63Hz
PFC Active PFC (>0.9 typical)
Power Good Signal 100-500ms
Efficiency 85% Typically
Protection UVP/OVP/SCP/OPP/NLO
Output Capacity 600W
Regulatory TUV/CB/CE/KC
Fan 120mm Silent Fan
Certifications 80 Plus
Connector 1 x MB 24(20+4) Pin
1 x 8(4+4) Pin EPS 12V
2 x 8(6+2) Pin PCI-E
7 x SATA
2 x Molex
1 x FDD
Net Weight 1.81 Kgs
Gross Weight 2.22 Kgs
