InWin Airforce Mid-Tower Chassis - Phantom Black



Try True DIY
Admit it, you love building things, especially PCs! So, if you're feeling exceptionally crafty and are up for a new type of PC build, InWin introduces this new chassis set called AIRFORCE!

Bulid, assemble and display with this detailed, 19-piece modular gaming chassis. There's a great feeling buliding a PC, but a more satisfying feeling building your chassis too.

Select your Character
Two different color schemes represent different character options. Team up with Phantom Black or Justice White AIRFORCE!



Anti-Dust Ventilation Filter
Two large anti-dust ventilation filters are equipped on the AIRFORCE chassis. Effectively reduces dust and protects the hardware of PCs.





User Friendly, Hassle Free Design
Build the chassis and assemble the system with ease. The hassle-free modular design of the AIRFORE structure is a breeze to build up and build in.(Tool-less features include: Drive cage, quick-release side panel, quick-release filters.)

Spacious Interior for Maximum Expandability
The spacious interior of AIRFORCE provides PC builders more options with their internal components. Compatible up to 12x13" E-ATX motherboards and 390mm high-ends graphics cards.

Optimal Thermal Solutions with Versatile Cooling Options
Cooling is an important function when running PCs. AIRFORCE provides versatile cooling options to enhance the thermal solutions.(fan configuration: 3x120mm Front and Top, 1x120mm Rear, 240/360mm radiator on top and front)



LUNA Hight Performance Fans Onboard!
InWin's LUNA AL120 fans are high performance fans and their enhanced PQ curve allow it to perform excellent heat dissipation in any chassis or on any radiator.



Super Transfer Speeds
AIRFORCE provides an USB 3.1 Gen 2 Type-C USB port for data transfer. Nothing is better than a high-speed data transfer and more time spent in gaming.

TECHNICAL SPECS

Model AIRFORCE
Model Number IW-CS-AIRFORCE-WHI, IW-CS-AIRFORCE-BLA
Color Justice White, Phantom Black
Case Type Mid Tower
Materials Tempered Glass, SECC, ABS
M/B Compatibility 12” x 13” (305 x 330 mm) E-ATX, ATX, Micro-ATX, Mini-ITX
Expansion Slots 8 x PCI-E
Maximum Compatibility VGA Card Length:
390 mm
CPU Heatsink Height: 170 mm
I/O Ports 1 x USB 3.1 Gen 2Type-C
2 x USB 3.0
HD Audio
Internal Drive Bays 4 x 2.5"
2 x 3.5"
Thermal Solution Compatibility Air Cooling Fans:
Front: 3 x 120 mm
Top: 3 x 120 mm
Rear: 1 x 120 mm
(4 InWin AL120 Fans Included)
Water Cooling Radiator:
Front: 1 x 360 mm
Top: 1 x 360 mm
* Number of fans pre-installed may vary based on different regions.
Power Supply Compatibility PSII : ATX12V
- Length up to 180mm
Product Dimension
(H x W x D) 537 x 270 x 528 mm
21.1 x 10.6 x 20.7”
Package Dimension
(H x W x D) 590 x 550 x 240 mm
23.2 x 21.6 x 9.4”
Net Weight 6.9 kg / 15.2 lbs
Gross Weight 11.2 kg / 24.7 lbs
