AC1200 Dual-Band Wi-Fi Router with four antennas and Parental Control

FEATURES

• Concurrent 300 Mbps(2.4GHz) and 867 Mbps (5GHz) throughput for high-speed wireless performance.
• Enjoy the ASUSWRT dashboard UI for easy setup and manage your router.
• Improved coverage and multi-device performance with four external antennas — two each for the 2.4 GHz and 5 GHz bands.
• Advanced parental control helps you protect your children from Internet addiction. You can restrict the times that each device can access the internet by applying scheduled time limits.
• ASUS Router App makes your connected life easier!
• Dual WAN function can connect two WAN connections at the same time, to avert network downtime that is caused by ISP.

Robust control and optimization with ASUSWRT
With the ASUSWRT dashboard UI, setup, monitor, and control network applications all in one intuitive area. On top of 30-second setup, multi-device detection, and flexible settings that make the most of your network performance. Dual WAN enables having two connections/ISPs on one router, with load balance and failover mode for added stability and redundancy to ensure uninterrupted internet access. Do you game a lot, or spend most of your time streaming videos? Whatever your planned use is, the RT-AC1200 V2 has Quality of Service (QoS) standards that let you select how much bandwidth is prioritized for virtually any task. Plus, the traffic monitor allows you to check your Web usage in a clear graphical interface.

Control your network anywhere
In your increasingly mobile-enabled life, having control over your network via an app is more important than ever. The new ASUS Router App is built from the ground-up to be both intuitive and robust, allowing you to setup your router, manage network traffic, diagnose connection issues and even update firmware, all without needing to boot up a PC.

Super-fast AC Wi-Fi with 256QAM™ Wi-Fi acceleration
Powered by 5th generation Wi-Fi (5G Wi-Fi), the 802.11ac chipset gives the RT-AC1200 V2 faster wireless speeds than N technology. At 2.4 GHz, it reaches 300 Mbps, while on the 5GHz band it blazes to 867 Mbps. The upgraded bandwidth has the higher capacity you need to increase Wi-Fi enjoyment at home. With notebooks, desktops, pads, and smartphones now all Wi-Fi-reliant, it’s time to upgrade to the next generation to expand you connectivity now and in the future.

Dual-Band Connectivity for Lag-Free Entertainment
Delivering both 2.4 GHz and 5 GHz concurrent bands up to 300Mbps and 867Mbps respectively, the RT-AC1200 V2 has a total speed of up to 1167Mbps connectivity to provide speed with stability. Perform basic internet tasks like Web browsing and file downloading under the 2.4 GHz band, while also simultaneously streaming 3D HD content and other demanding applications smoothly on the 5 GHz band.

Easy 3-step setup
Use your smartphone, tablet, or PC to effortlessly set up your ASUS router in less than 30 seconds¹ and in only 3 easy steps. Simply connect the cables to the router, open a Web browser, and follow the setup wizard to get you to the internet in no time.

TECHNICAL SPECS

Model Name
RT-AC1200_V2
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.3
IEEE 802.3u
IEEE 802.11i
IEEE 802.11e
IPv4
IPv6
Product Segment
AC1200 enhanced AC performance : 300+867 Mbps
Data Rate
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
802.11n : up to 300 Mbps
802.11ac : up to 867 Mbps
Antenna
External antenna x 4
Transmit/Receive
MIMO technology
2.4 GHz 2 x 2
5 GHz 2 x 2
Memory
16 MB Flash
64 MB RAM
Operating Frequency
2.4GHz
5GHz
Ports
RJ45 for 10/100Mbps BaseT for WAN x 1
RJ45 for 10/100Mbps BaseT for LAN x 4
Button
WPS Button, Reset Button, Power Button
Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 0.5 A current
Package content
1 x RT-AC1200 V2 Wi-Fi router
1 x Power adapter
1 x QSG
1 x Warranty card
Product Weight (g)
271 g
AiMesh
AiMesh:No
Primary AiMesh router:No
AiMesh node:No
Router APP
ASUS Router APP:Yes
Game
Game Boost/acceleration:No
WTFast:No
Alexa
Support Alexa skill:No
IFTTT
Support IFTTT:No
AiProtection
AiProtection:No
Router Security Assessment:No
Malicious site blocking:No
Two-Way IPS:No
Infected Device Prevention and Blocking;No
Parental Control
Parental Control:Yes
Parental Control Customized Internet schedule:Yes
Traffic Control
Adaptive QoS:No
Bandwidth Monitor:No
Bandwidth limiter:Yes
Maximum Bandwidth limiter rule:32
Traditional QoS:Yes
Maximum Traditional QoS rule:32
Traffic Monitor:Yes
Real-time traffic monitor:Yes
Wired Traffic Monitor:Yes
Wireless Traffic Monitor:Yes
Traffic Analyzer:No
Traffic analysis period:Daily, Weekly, Monthly
Website history:No
Wireless
IPv6:Yes
MU-MIMO:No
Wi-Fi Encryption:Open system, WPA/WPA2-Personal, WPA/WPA2-Enterprise
UTF-8 SSID:Yes
Guest Network:Yes
Maximum Guest Network rule:2.4GHz x3, 5GHz x3
Guest Network Encryption:Open system, WPA/WPA2-Personal
WPS:Yes
Wi-Fi MAC address filter:Yes
Maximum MAC filters:64
Wireless scheduler:Yes
Airtime fairness:Yes
RADIUS Server:Yes
Universal beamforming:No
Explicit beamforming:Yes
WAN
Internet connection Type:PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN:Yes
WAN Aggregation:No
3G/4G LTE dongle:No
Android tethering:No
Port forwarding:Yes
Maximum port forwarding rule:64
Port triggering:Yes
Maximum port triggering rule:32
DMZ:Yes
DDNS:Yes
NAT Passthrough:PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
LAN
DHCP Server:Yes
IGMP snooping:Yes
IPTV:Yes
LAN Link Aggregation:No
Manually assign IP address:Yes
Maximum manually assign IP address rule:64
VPN
VPN Client L2PT:No
VPN Client OVPN:No
VPN Client PPTP:No
VPN Server IPSec:No
VPN Server OVPN:No
VPN Server PPTP:No
VPN Fusion:No
USB application
File System:FAT16, FAT32, NT3G
HDD hibernation:No
Safely Remove disk:No
AiCloud:No
Download master:No
AiDisk:No
Media Server:No
Time Machine:No
Samba Server:No
FTP Server:No
Shared Folder privileges:No
Administration
Operating mode:Accesspoint, Router
Operating system:ASUSWRT
Free OS upgrade:Yes
Firewall:Yes
Maximum Firewall keyword filter:64
Maximum Firewall network service filter:32
Maximum Firewall URL filter:64
Wake on LAN (WOL):Yes
SSH:Yes
Configuration backup and restore:Yes
Diagnosis tools:Yes
Feedback system:Yes
System log:Yes
3 Years Warranty
